OUTPUT
|
| Output Volt Amp Capacity (VA) |
1500 |
| Output kVA Capacity (kVA) |
1.5 |
| Output Watt Capacity (Watts) |
1200 |
| Output kW Capacity (kW) |
1.2 |
| Output Capacity Details |
OVERLOAD CAPACITY: Supports inverter operation up to 105% load continuously, 125% load for 3 minutes; 150% load for 30 seconds and >150% load for 0.5 seconds before switching to BYPASS (when bypass input voltage and frequency are WITHIN bypass limits) or SHUTDOWN (when bypass input voltage or frequency are OUTSIDE bypass limits) |
| Power Factor |
0.8 |
| Crest Factor |
3:1 |
| Nominal Output Voltage(s) Supported |
200V; 220V; 230V; 240V |
| Nominal Voltage Details |
230V default |
| Frequency Compatibility |
50 / 60 Hz |
| Frequency Compatibility Details |
Output frequency matches input nominal on startup, defaults to 50 Hz on cold-start |
| Output Voltage Regulation (Line Mode) |
+/- 2% |
| Output Voltage Regulation (Economy Line Mode) |
+/- 10% |
| Output Voltage Regulation (Battery Mode) |
+/- 2% |
| Output Receptacles |
(6) C13 |
| Included Output Power Cables |
Includes 2 C13 to C14 output power cables |
| Load Management Receptacles |
Two switchable three-outlet C13 load banks |
| Hot-Swap PDU options |
PDUBHV10 (2U / 8 C13 outlets) |
| Output AC Waveform (AC Mode) |
Sine wave |
| Output AC Waveform (Battery Mode) |
Pure Sine wave |
|
INPUT
|
| Rated input current (Maximum Load) |
6.4A |
| Nominal Input Voltage(s) Supported |
200V AC; 220V AC; 230V AC; 240V AC |
| UPS Input Connection Type |
C14 inlet |
| UPS Input Connection Description |
IEC320-C14 input connection accepts a variety of detachable cordsets to match country or site-specific wall receptacles |
| Input Circuit Breakers |
10A |
| Input Phase |
Single-Phase |
|
BATTERY
|
| Full Load Runtime (min.) |
4.5 min. (1200w) |
| Half Load Runtime (min.) |
12 min. (600w) |
| Expandable Battery Runtime |
Extended runtime supported via optional external battery packs |
| External Battery Pack Compatibility |
BP48V24-2U(limit 1); BP48V60RT-3U(multi-pack compatible); BP48V27-2US(multi-pack compatible) |
| DC System Voltage (VDC) |
48 |
| Battery Recharge Rate (Included Batteries) |
Less than 6 hours from 10% to 80% (typical, full load discharge) |
| Internal UPS Replacement Battery Cartridge |
RBC94-2U |
| Battery Access |
Front panel battery access door |
| Battery Replacement Description |
Hot-swappable, user replaceable batteries |
| Expandable Runtime |
Yes |
|
VOLTAGE REGULATION
|
| Voltage Regulation Description |
Online, double-conversion power conditioning |
| Overvoltage Correction |
2% output voltage regulation during overvoltages to 275 |
| Undervoltage Correction |
2% output voltage regulation during undervoltages to 156 |
| Severe Undervoltage Correction |
2% output voltage regulation during undervoltages to 130 (under 70% load only) |
|
USER INTERFACE, ALERTS & CONTROLS
|
| Switches |
2 Switches control off/on power status and alarm-cancel/self-test operation |
| Alarm Cancel Operation |
Power-fail alarm can be silenced using alarm-cancel switch |
| Audible Alarm |
Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions |
| LED Indicators |
14 LEDs indicate line power, online mode, economy/bypass mode, on-battery, overload, battery low, replace battery and fault status information; 4-LED meter displays load and battery charge levels; LED panel rotates for viewing in rack/tower formats |
|
SURGE / NOISE SUPPRESSION
|
| UPS AC Suppression Joule Rating |
480 |
| UPS AC Suppression Response Time |
Instantaneous |
| EMI / RFI AC Noise Suppression |
Yes |
|
PHYSICAL
|
| Included Mounting Accessory Description |
4 post rackmount installation accessories included |
| Installation Form Factors Supported with Optional Accessories |
2 post rackmount(2POSTRMKITWM); Wallmount(2POSTRMKITWM); Tower(2-9USTAND) |
| Primary Form Factor |
Rackmount |
| UPS Power Module Dimensions (hwd, cm) |
8.9 x 44.4 x 48.3 |
| Rack Height (U Spaces) |
2 |
| UPS Power Module Weight (kg) |
21.6 |
| UPS Shipping Dimensions (hwd / cm) |
24.8 x 51.4 x 61 |
| Shipping Weight (kg) |
27.2 |
| Cooling Method |
Fan |
| UPS Housing Material |
Steel |
|
ENVIRONMENTAL
|
| Operating Temperature Range |
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius |
| Storage Temperature Range |
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius |
| Relative Humidity |
0 to 95%, non-condensing |
| AC Mode BTU / Hr. (Full Load) |
664.2 |
| AC Economy Mode BTU / Hr. (Full Load) |
260.4 |
| Battery Mode BTU / Hr. (Full Load) |
664.2 |
| AC Mode Efficiency Rating (100% Load) |
86% |
| AC Economy Mode Efficiency Rating (100% Load) |
94% |
| Audible Noise |
45dBA At Front Side 1 Meter |
|
COMMUNICATIONS
|
| Communications Interface |
USB (HID enabled); DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface |
| Network Monitoring Port Description |
Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure communications |
| PowerAlert Software |
Included |
| Communications Cable |
USB and DB9 cabling included |
| WatchDog Compatibility |
Supports Watchdog application, OS and hard-reboot restart options for remote applications |
|
LINE / BATTERY TRANSFER
|
| Transfer Time |
No transfer time (0 ms.) in online, double-conversion mode |
| Low Voltage Transfer to Battery Power (Setpoint) |
160V (100% load), 130V ( <70% load) |
| High Voltage Transfer to Battery Power (Setpoint) |
275 |
|
SPECIAL FEATURES
|
| Cold Start (Startup in Battery Mode During a Power Failure) |
Cold-start operation supported |
| High Availability UPS Features |
Automatic inverter bypass; Hot swappable batteries |
| Green Energy-Saving Features |
High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of economy mode operation |
|
CERTIFICATIONS
|
| UPS Certifications |
CE |
| UPS Certification Details |
Kuwait, EMI Approvals: EN62040-2 |
|
WARRANTY
|
| Product Warranty Period (Worldwide) |
2-year limited warranty |
|
