Interface
|
| Fixed WAN Port |
1x RJ-11 |
| LAN/WAN Switchable Port |
1x GbE RJ-45 |
| Fixed LAN Port |
3x GbE RJ-45 |
| USB Port |
2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer |
| 2.4G WLAN |
300Mbps 802.11n (n/Vn model) |
| RJ-11 for Voice |
2 (Vn model) |
Capacity
|
| Max. Number of NAT Sessions |
30,000 |
| Max. Concurrent VPN Tunnels |
2 |
| Max. Concurrent OpenVPN + SSL VPN |
2 |
VDSL/ADSL
|
| VDSL Standards |
ITU-T G.993.1 (VDSL), G.997.1, G.993.2 (VDSL2) |
| VDSL2 Profile |
8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a |
| VDSL Band Plan |
997 |
| G.Vectoring |
|
| Loop diagnostic mode |
|
| ADSL Standards |
ANSI T1.413, ITU-T G.992.1(G.dmt), G.992.2 (G.lite) |
| ADSL2 Standards |
ITU-T G.992.3, G.992.3 Annex J |
| ADSL2+ Standards |
ITU-T G.992.5, G.992.5 Annex M |
| DSL Forum |
TR-114, TR-048/67, TR-100 |
Internet Connection
|
| IPv4 |
PPPoE, DHCP, Static IP, PPTP/L2TP |
| IPv6 |
PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| Multi-VLAN/PVC |
|
| WAN Failover |
|
| Connection Detection |
ARP, Ping |
| Dynamic DNS |
|
LAN Management
|
| VLAN |
802.1q Tag-based, Port-based |
| Max. Number of VLAN |
8 |
| DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
| Port Mirroring |
|
| Local DNS Server |
|
| Conditional DNS Forwarding |
|
| Web Portal |
|
Networking
|
| Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP |
| Multicast |
IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour |
| SMB File Sharing |
(Requires external storage) |
VPN
|
| LAN-to-LAN |
|
| Teleworker-to-LAN |
|
| Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, IKEv2 |
| User Authentication |
Local, mOTP |
| IKE Authentication |
Pre-Shared Key, X.509 |
| IPsec Authentication |
SHA1, SHA256, MD5 |
| Single-Armed VPN |
|
| NAT-Traversal (NAT-T) |
|
Firewall & Content Filtering
|
| NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
| ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
| VPN Pass-Through |
PPTP, L2TP, IPsec |
| IP-based Firewall Policy |
|
| Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
| DoS Attack Defense |
|
Bandwidth Management
|
| IP-based Bandwidth Limit |
|
| IP-based Session Limit |
|
| QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
| VoIP Prioritization |
|
Wireless LAN (n/Vn model)
|
| Number of SSID |
4 |
| Security |
WEP, WPA, WPA2, WPS |
| Authentication |
Pre-Shared Key, 802.1x |
| WDS |
Bridge, Repeater |
| Access Control |
Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
| WMM |
|
VoIP Gateway (model Vn)
|
| Protocol |
SIP, RTP/RTCP, ZRTP |
| SIP Registrars |
12 |
| Dial Plan |
Phone Book, Digit Map, Call Barring, Regional |
| Call Features |
Call Waiting, Call Transfer, Scheduled DND, Hotline |
| Voice Codec |
G.711 A/u law, G.723.1, G.726, G.729 A/B |
| Caller ID |
FSK_ETSI, FSK_BELLCORE, DTMF |
Management
|
| Local Service |
HTTP, HTTPS, Telnet, SSH, TR-069 |
| Config File Export & Import |
|
| Config File Compatibility |
Vigor2710 |
| Firmware Upgrade |
TFTP, HTTP, TR-069 |
| 2-Level Administration Privilege |
|
| Access Control List |
|
| Syslog |
|
| Notification Alert |
SMS, E-mail |
| SNMP |
v2, v2c, v3 |
| Managed by VigorACS |
|
Physical
|
| Power Supply |
DC 12V @ 2A |
| Dimension |
181mm x 125mm x 40mm |
| Operating Temperature |
0 to 45°C |
| Storage Temperature |
-25 to 70°C |
| Operating Humidity (non-condensing) |
10 to 90% |
