OUTPUT |
| Output Volt Amp Capacity (VA) | 3000 | | Output kVA Capacity (kVA) | 3 | | Output Watt Capacity (Watts) | 2700 | | Output kW Capacity (kW) | 2.7 | | Power Factor | .9 | | Nominal Output Voltage(s) Supported | 220V; 230V; 240V | | Nominal Voltage Details | 230v nominal inverter output voltage | | Frequency Compatibility | 50 / 60 Hz | | Output Voltage Regulation (Line Mode) | +6%, -15% | | Output Voltage Regulation (Battery Mode) | +/-5% | | Output Receptacles | (8) C13; (1) C19 | | Included Output Power Cables | Set of 3 C13 to C14 power cables included | | Load Management Receptacles | Two switchable single outlet C13 load banks | | Output AC Waveform (AC Mode) | Pure Sine wave | | Output AC Waveform (Battery Mode) | Pure Sine wave |
|
INPUT |
| Rated input current (Maximum Load) | 14.1A | | Nominal Input Voltage(s) Supported | 230V AC | | UPS Input Connection Type | C20 inlet | | UPS Input Connection Description | IEC320-C20 input connection accepts a variety of user supplied detachable C19 output cordsets to match country or site specific power sources | | Input Circuit Breakers | 20A | | Input Phase | Single-Phase |
|
BATTERY |
| Full Load Runtime (min.) | 3.9 min. (2700w) | | Half Load Runtime (min.) | 11.1 min. (1350w) | | Expandable Battery Runtime | Extended runtime supported via optional external battery packs | | External Battery Pack Compatibility | BP48V24-2U(limit 1); BP48V60RT-3U(multi-pack compatible); BP48V27-2US(multi-pack compatible) | | DC System Voltage (VDC) | 48 | | Battery Recharge Rate (Included Batteries) | Less than 5 hours from 10 to 90% (typical, full load discharge) | | Internal UPS Replacement Battery Cartridge | RBC58-2U | | Battery Access | Front panel battery access door | | Battery Replacement Description | Hot-swappable, replaceable batteries | | Expandable Runtime | Yes |
|
VOLTAGE REGULATION |
| Voltage Regulation Description | Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 158 to 278 | | Overvoltage Correction | Input voltages between 244 and 278 are reduced by 12% | | Undervoltage Correction | Input voltages between 206 and 183 are boosted by 12% | | Severe Undervoltage Correction | Input voltages between 158 and 183 are boosted by 24% |
|
USER INTERFACE, ALERTS & CONTROLS |
| Front Panel LCD Display | Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options) | | Switches | 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions | | Alarm Cancel Operation | Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option available | | Audible Alarm | Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions |
|
SURGE / NOISE SUPPRESSION |
| UPS AC Suppression Joule Rating | 350 | | EMI / RFI AC Noise Suppression | Yes | | AC Suppression Response Time | Instantaneous |
|
PHYSICAL |
| Included Mounting Accessory Description | 4 post rackmount installation hardware included | | Installation Form Factors Supported with Optional Accessories | 2 post rackmount(2POSTRMKITWM); Wallmount(2POSTRMKITWM); Tower(2-9USTAND) | | Primary Form Factor | Rackmount | | UPS Power Module Dimensions (hwd, cm) | 8.9 x 44.4 x 49.5 | | Rack Height (U Spaces) | 2 | | UPS Power Module Weight (kg) | 28.5 | | UPS Shipping Dimensions (hwd / cm) | 22.9 x 60.3 x 52.1 | | Shipping Weight (kg) | 33 | | Cooling Method | Fan | | UPS Housing Material | Steel |
|
ENVIRONMENTAL |
| Operating Temperature Range | +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius | | Storage Temperature Range | +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius | | Relative Humidity | 0 to 95%, non-condensing | | AC Mode BTU / Hr. (Full Load) | 158 | | AC Mode Efficiency Rating (100% Load) | 98% |
|
COMMUNICATIONS |
| Communications Interface | USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface | | Network Monitoring Port Description | Supports detailed monitoring of UPS and site power conditions | | PowerAlert Software | Included | | Communications Cable | USB, DB9 and EPO cabling included | | WatchDog Compatibility | Supports Watchdog application, OS and hard-reboot restart options for remote applications |
|
LINE / BATTERY TRANSFER |
| Transfer Time | 6 milliseconds (AC to battery mode), 1 millisecond (Battery to AC mode) | | Low Voltage Transfer to Battery Power (Setpoint) | 158 | | High Voltage Transfer to Battery Power (Setpoint) | 278 |
|
SPECIAL FEATURES |
| Cold Start (Startup in Battery Mode During a Power Failure) | Cold-start operation supported | | High Availability UPS Features | Hot swappable batteries | | Green Energy-Saving Features | Greater than 95% efficiency – GREEN UPS; Individually controllable load banks; Schedulable daily hours of economy mode operation |
|
CERTIFICATIONS |
| UPS Certifications | CE; ROHS (Restriction of Hazardous Substances) | | UPS Certification Details | IEC 62040-1, IEC 62040-2 Class A EMI, GOST |
|
WARRANTY |
| Product Warranty Period (Worldwide) | 2-year limited warranty |
|
